Description
DOMETIC SeaStar PA1200-3 Power Assist Hydraulic Steering Pump, 15' Harness
The Dometic SeaStar Power Assist PA1200-3 is an electronically controlled gear pump integrated into the hydraulic steering system between the helm and steering cylinder. It enhances steering by directing fluid from the helm pump through the gear pump to the steering cylinder(s). The helm controls both speed and direction, while the power assist functions as the active component that amplifies steering force. The gear pump’s speed is proportional to the helm’s movement—turning the wheel faster increases pump speed. When not in use, the power assist remains idle, drawing only standby power.
SeaStar Power Assist Update:
Dometic Marine is pleased to announce that we have updated our very popular SeaStar Power Assist product and have eliminated redundant models. The new -3 series of SeaStar Power Assist pumps have undergone a performance improvement with new electronics and the addition of ORB fittings similar to steering helms and cylinders.
Key Features
- ORB Fittings
- Dramatically reduces steering effort in heavy or high torque applications
- Easy install. Wall or Floor mount
- OEM or retro-fit
- Simple add-o to an existing SeaStar steering system (from 1.4 to 2.4 SeaStar helms)
- Compatible w/ power purge system
- Return to manual in failure mode
- Suitable for boats w/ multiple engines and rudders, multiple steering stations, and autopilots
- Ignition protected (SAE J-1171). ABYC, CE, NMMA, ISO 10592 Approved
- Voltage: 12V
- System Pressure: 1000 psi MAX
- Current Draw: 40 A MAX, 60 A Peak (1 A System Electronics)
- 15' Harness
Old part number PA13152 superseded to new part number PA1200-3
Warranty Information
Specs
|
MPN:
|
PA12003
|
