Description
Rockford Fosgate M2 300 Watt 4-Channel Element Ready Amplifier M2-300X4
Designed to withstand the elements, the M2-300X4 Element Ready™ amplifier is a 300 watt, full-range class-D model, capable of operating at 4Ω or 2Ω stereo, and 4Ω bridged/mono. This amplifier is extremely efficient because of its class D technology which reduces demand on the electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases.
The M2 Series were developed for marine audio environments that feature UV resistant protection and special internal conformal coating that protect the electronics from water. It’s designed for those who want a reliable amplifier – with all the power and performance you’ve come to expect from Rockford Fosgate – at an economical price. Rockford Fosgate amplifiers are renowned world-wide for being “under rated,” easily surpassing all specifications, and most importantly, generating more power than their ratings. The latest generation of M2 Series amplifiers are also designed to be easy to setup and configure, making them perfect for use in any application.
FEATURES AT A GLANCE
- UV stable powder coated cast aluminum heatsink
- Zinc Nickel-plated Marine grade brass connection terminals
- Element Ready™ design protects against outdoor exposure
- Optimized using AudioGraph PowerCube measurement tool
- C.L.E.A.N. input/output clip detection and indicator LEDs
- Conformal coated circuit board protects against dust and water
- 2/4 channel input switch
- RCA pass-thru outputs
- Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- Short Circuit & Over Current Protection
- Top Mounted Control Panel
- Integration with OEM and Aftermarket Radios
- Integrated Power and Speaker Terminals
- Balanced Differential Inputs eliminates noise picked up by signal cables
- Quality & Performance tested using proprietary RATS (Rockford Automated Testing System)
- Low Impedance Stability
- 2-Year Warranty
- Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
- CEA-2006 Compliant & CE Compliant
- "Auto-Sense" turn-on with remote out (high level in)
Specs
|
MPN:
|
M2-300X4
|
Total Power: |
300 Watts |
Bridgeable: |
Yes |
Frequency Response: |
20 Hz - 20 kHz |
Input Sensitivity: |
Low-Level: 150 mV - 4 V High-Level: 450 mV - 12 V |
Remote Controls: |
No |
Power Wire Gauge: |
4 AWG |
Power Input Connector: |
Compression Terminal Block |
Speaker Wire Gauge: |
8 AWG |
Speaker Output Connector: |
Compression Terminal Block |
Cooling: |
Convection |
Recommended Fuse: |
60 A |
Max. Current Draw: |
39 A |
Height: |
1.9" |
Width: |
6.8" |
Depth: |
10.1" |
